Hardware | |
Imaging Instrument | 4 Inch Refractor at Prime Focus |
Focal Length | 530 mm |
Focal Ratio | 5.0 |
Imaging Camera | QSI 683ws-g |
Guiding Instrument | OAG via QSI IGP |
Guiding Camera | Starlight Xpress Lodestar X2 |
Software | |
Image Capture | Sequence Generator Pro |
Guiding | PHD v2 |
Image Processing | PixInsight |
Exposure | ||||||
This is a 4 panel mosaic captured over the summer and fall of 2015. Due to weather conditions, I was not able to capture as much data as this image needs. I will continue it in 2016 and post a new and better image next year. In the meantime, high resolution versions will not be available. | ||||||
Total Image Frames | 632 | |||||
Total Image Time | 38 hours 24 minutes | |||||
Per Panel | Total | Start Date | End Date | |||
Filter | Frames | Exposure | Frames | Elapsed Time | Start Date | End Date |
Lum | 65 | 120 sec | 260 | 8h 40m | 10-Jul-2015 | 13-Nov_2015 |
Red | 25 | 120 sec | 100 | 3h 20m | 17-Jul-2015 | 13-Nov_2015 |
Green | 21 | 120 sec | 84 | 2h 48m | 17-Jul-2015 | 13-Nov_2015 |
Blue | 27 | 120 sec | 108 | 3h 36m | 05-Aug-2015 | 13-Nov_2015 |
Hα | 9 | 900 sec | 36 | 9h | 22-Jul-2015 | 12-Nov_2015 |
Oiii | 11 | 900 sec | 44 | 11h | 22-Jul-2015 | 12-Nov_2015 |
Imaging Locations | Ft McKavett TX | |||||
General Nathan Twining Observatory NM | ||||||
Kenton OK - Okie-Tex Star Party | ||||||
Magdalena NM | ||||||
Tijeras NM |
Other Image Sizes |
Full Resolution Image - wait until next year! |
LRGBHaO3 Big Image (2400x1800) |
LRGBHaO3 Large Image (1200x900) |
LRGBHaO3 Medium Image (800x600) |
LRGBHaO3 Small Image (700x525) |
Luminance (1200x900) |
Inverted Luminance (1200x900) |
